2MHz Φ29mm ultrasonic acoustic chemical transducer

2MHz Φ29mm ultrasonic acoustic chemical transducer
2MHz Φ29mm ultrasonic acoustic chemical transducer
2MHz Φ29mm ultrasonic acoustic chemical transducer
2MHz Φ29mm ultrasonic acoustic chemical transducer
Part name : 2MHz Φ29mm ultrasonic acoustic chemical transducer
Part No. : LSU292MPIFH17G
Description of goods

Applications:

Ultrasonic flow meter, under water range detection, liquid concentration and density measurement etc


Features:

*Rugged sealed contruction

*Cylindrical design for easy installation


Technical parameter:


Center Frequency: 2M ± 60KHz

Detectable range: 0.02 ~ 2m
Mini. parallel Resistance: 30 Ω ± 20%
Capacitance: 4000pF ± 20% @1KHz

Echo Sensitivity: 500mV echo amplitude @0.6m, under 200Vpp

Working Voltage: Crest voltage < 600Vpp

Working temperature: -40 ~ +80
Pressure: ≤3Kg or 0.3MPa
Angle: Half-power angle @-3dB: 6
° ± 1, Sharp Angle: 14° ± 4
Housing Material: POM
Corrosion Resistance: can be used under the environment of weak acid or weak base

Installation dimensions: 28.6mm
Protection class: IP68
Wiring instructions: contact for more details
